6MM x 10 Meters Helical Bar Coil

Item specifics :

Condition :

Brand New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is available in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.

Brand :

HeliMate

Country/Region of Manufacture :

Australia

Item description from the seller :

HeliMate – 1 length  of 6mm x 10,000mm Helical Crack Stitching coil

Grade 316 Stainless Steel | Structural Masonry Reinforcement System

Overview :

HeliMate – 6mm x 10m Helical Bar Coil
Premium 316 Stainless Steel | Structural Masonry Reinforcement | Crack Stitching Solution

🧱 Overview:
HeliMate’s 6mm x 10 metre helical bar coil is a flexible, high-strength masonry reinforcement product ideal for structural crack stitching and repairing horizontal fractures in brickwork or blockwork. Manufactured from marine-grade 316 stainless steel, this helical bar offers superior corrosion resistance, making it suitable for both internal and external applications, including coastal and marine environments.

Technical Specifications :

• Quantity: 1 length of 6MM x 10 Meters

• Bar Diameter: 6.0 mm (±0.1 mm)

• Bar Length: 10,000 mm

• Material: Cold-formed AISI 316 stainless steel

• Minimum Yield Strength: > 940 MPa

• Ultimate Tensile Strength: > 1400 MPa

• Helical Pitch: ~30 mm

• Grout Compatibility: Non-shrink cementitious or epoxy grout

Installation Applications :

• Horizontal crack stitching across fractured masonry

• Reinforcement around openings (windows, doors)

• Load redistribution above lintels and between wall sections

• Suitable for double-wythe and cavity wall structures

• Can be installed in pre-cut 8–10 mm wide x 30–40 mm deep horizontal bed-joint chases

Installation Guide :

See diagram below for standard horizontal crack stitching layout. Typically, bars are installed at 300–600 mm vertical centers depending on wall height and crack pattern. Bars are fully embedded in grout and extend minimum 500 mm either side of the crack.

Standards Compliance :

• AS/NZS 2699.3:2020 – Wall ties and connectors for masonry

• AS 3700:2018 – Masonry Structures

• AS/NZS ISO 3506-1:2020 – Mechanical properties of corrosion-resistant stainless steels

• BS EN 845-1 / 998-2 / 1996-1-1 (for international compatibility)

• Seismic retrofit compliant per AS 3826 and AS 5216:2021 (Design of post-installed and cast-in fastenings)

Key Advantages :

• Superior corrosion resistance for harsh environments

• Cold-formed for high yield and flexibility

• Enhances wall ductility and crack resistance

• Mechanically interlocks with grout – no mechanical anchors required

• Low-profile, non-disruptive retrofit method

AU Proudly Australian :

Helical Australia supplies trade-quality helical reinforcement solutions engineered for performance, safety, and compliance. Trusted by structural engineers, heritage contractors, and builders nationwide.
